Seastar solutions hydraulic power assisted steering system
Steering systems & helms
Features
Dramatically reduces wheel torque
Easy to install
Simple ‘add on’ to an existing SeaStar manual system (optimal performance achieved when used with SeaStar 1.4 2.0 pumps)
OEM or Retro fit
Compatible with power purge system
Reverts to manual mode in the case of power loss.
Suitable for use with autopilots
12v or 24v operation
Wall or floor mounted
Wiring harness, and mounting bracket included
Ignition protected (SAE J-1171)
ABYC, CE, NMMA, ISO 10592 Approved
Technical Data
SeaStar Power Assist steering brings automotive-type steering comfort and control to
powerboats. The addition of a Power Assist unit will greatly reduce steering effort and enhance
the boating experience for everyone. The SeaStar Power Assist steering unit is designed for
use with SeaStar manual hydraulic steering systems and is suited for all heavy / high torque
steering applications.
Technical Specifications
Voltage: 12V or 24V (automatically recognized)
System Pressure: 1000 psi MAX (1500 psi MAX Power Assist Pro)
Current Draw: 40 A MAX, 60 A PEAK (1 A System Electronics)
Typical Applications
150hp+ single outboards
Heavy 4 stroke outboards
Twin/Triple outboards
High performance bass boats (SeaStar Power Assist Pro)
Non counter rotating twin outboards
Inboards where rudder torque makes wheel effort heavy or uncomfortable
Designed for difficult and hard to steer boats
Suitable for all O/B, I/O, I/B powered boats, equipped with standard hydraulic steering.
Seastar solutions hydraulic power assisted steering system
Seastar solutions hydraulic power assisted steering system
№ каталог
Описание
Цена
704866
SeaStar Hydraulic Power Assisted Steering System - OEM No. PA1200-2
--
Номер в каталоге:
704866
Описание:
SeaStar Hydraulic Power Assisted Steering System - OEM No. PA1200-2
